CNCTOPBAOS 4 Axis DDCSV3.1 Offline Stand Alone CNC Controller System PLC | 500KHz, DC24V, VFD/Spindle/Servo/Stepper Motor Motion Control, Read M/G-code For CNC Router Milling Engraving Machine,Lathe
Product details
| Management number | 247181503 | Release Date | 2026/08/16 | List Price | US$102.00 | Model Number | 247181503 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Brief introduction: DDCSV3.3 is a firmware upgrade version of DDCSV3.1,it is a 4 axis motion controller,the highest output pulse per axis is 500KHz;This provides high control precision for stepper motors and servo motors;The DDCS operates as a stand alone system without the need of a computer,and it needs two 24V DC power supplies
- Compatible with G code set: 5 inches TFT Screen ; Resolution ratio: 480x272 ;16 photoelectric isolated digital inputs ; 3 photoelectric isolated digital outputs ; All operations are controlled by only 17 keys and it supports the FANUC with high universality to be compatible with G code set,with 4G USB flash disk support for G code file input,no size limited of the G-code file
- Brief technical feature: 16 photoelectric isolated digital inputs,3 photoelectric isolated digital outputs ; Analog spindle control 0-10V spindle control can be modified as PWM output; ARM9 main control chip,FPGA core algorithm chip ; Jog function for each axis continuous, step, defined distance; Customer can define the distance ; Support NPN type limited switch
- Power requirements: The Power Supply for the controller is 24VDC,DDCSV3.3 needs two power supplies,main power is for system,IO port is for input and output ports, Current is not less than 1A;Because of the IO power,system can supply the power for all IO ports.So no need the external power supply for IO port anymore
- Applications: The DDCV3.3 can be used for many styles and types of CNC machines. Lathes, CNC Routers,Pick&Place and Milling Machine,lathe machine and cutters are just a few examples
| UPC | 681385631265 |
|---|---|
| ASIN | B07SR854D1 |
| Color | silver, gray |
| Model | DDCS V3.1 |
| Voltage | 24 volts |
| Brand Name | CNCTOPBAOS |
| Item Weight | 0.88 kg |
| Part Number | DDCS V3.1 |
| Display Type | TFT |
| Manufacturer | Changzhou Rattm Motor Co.,Ltd |
| Material Type | Metal |
| Number of Items | 1 |
